Broz 200

$700.00 Price drop reminder
  • Product Code: Broz 200
  • Availability: 1000

Total $700.00
This product has a minimum quantity of 32
 Model Broz 2016
Dimension.(L×W×H)(mm) 2080×840×1180
Wheel base(mm) 1360
Ground (mm) 265
Seat height(mm) 860
Turning angle 48°
Min turning radius(mm) 2120
Front/rear sprocket teeth 17/46
Gearshift 5-forward
Fuel tank(L) 9L
 Fuel Type Gasoline
Max. Load Capacity(kg) 150
Dead Weight(kg) 119
Displacement/Power(ml/kw): 200
Eco fuel consumption(L/100km) 2.2L
Brake Mode Front Wheel Disc brake
Rear Wheel Disc brake
  Front Wheel Manual
Brake Operation Mode Rear Wheel kick
Wheel Rim Type Front spoke wheel:   1.85×19
Rear spoke wheel:        2.15×18
Tire type With tube
Front tire 80/100-19
Rear tire 110/100-18
Head light 12V  35W/35W
Winker 12V  10W
Batterymm With acid: 12V7A
Engine type 1-Cylinder, 4-stroke, air-cool, OHC
Engine Model 163FML-B
Start Electric+kick
Ignition CDI
Bore×Distance 63.5*62.2
Displacement(ml) 197
Compression rate 9.21
Magneto 12V 8head full phase
Oil capacity(ml) 1100
Spark plug D8EANGK
Spark clearance(mm) 0.6~0.7
Valve clearance(mm) 0.04~0.06
Lubriation press+splash
Carburetor PZ30
Transmission Constant mesh
Clutch type Manual, multi-disc
Initial trans rate 3.333
Gearshift rates 1st: 2.769 2nd: 1.882 3rd: 1.400 4th 1.130fifth: 0.960
Final trans Chain
Rotation direction Facing shaft, unclock wise
Size(mm) 388×324×446
N.W.(kg) 31
Rated power 10.2KW(8000r/min±5%)
Max power 10.8KW(8000r/min±5%)
Max torque 13N·m(7000r/min)
