GN125 Original

Suzuki engine

$500.00 Price drop reminder
  • Brand: Symcot
  • Product Code: GN125 Original
  • Availability: 1000
  • Promotion:
    Full reduction Up to $100.00 and up to 1 quantity discount $20.00 and give gifts

Total $500.00
 Model GN125
Dimension.(L×W×H)(mm) 1945×815×1110
Wheel base(mm) 1280
Min ground clearance (mm) 175
Seat height(mm) 760
Turning angle 48°
Min turning radius(mm) 2120
Front/rear sprocket teeth 17/42
Gearshift 5-forward
Fuel tank(L) 13L
 Fuel Type Gasoline
Max. Load Capacity(kg) 150
Dead Weight(kg) 115
Displacement/Power(ml/kw): 124cc
Eco fuel consumption(L/100km) 1.8
Brake Mode Front Wheel:Disc brake
Rear Wheel:Drum brake
Wheel Rim Type Front aluminum wheel:       1.60×18
Rear aluminum wheel:          2.10×16
Tire type With tube
Front tire 3.00-18
Rear tire 110/90-16
Head light 12V  35W/35W
Winker 12V  10W
Batterymm Maintenance Free: 12V7AH    114×71×106

Engine type 1-Cylinder, 4-stroke, air-cool, OHC
Engine Model GS125
Start Electric+kick
Ignition CDI
Bore×Distance 62×49.5
Displacement(ml) 124
Compression rate 8.6:1
Magneto 12V 8head full phase
Oil capacity(ml) 1100
Spark plug D8TC
Spark clearance(mm) 0.6~0.7
Valve clearance(mm) 0.04~0.06
Lubriation Press+splash
Carburetor PZ27
Transmission Constant mesh
Clutch type manual, wet, multi-disc
Initial trans rate 3.333
Gearshift rates 1st: 2.769 ,2nd: 1.882,third; 1.400,forth: 1.130,fifth: 0.960
Final trans Chain
Rotation direction Facing shaft, unclock wise
Size(mm) 358×324×446
N.W.(kg) 31
Rated power 7.5KW(8500r/min±5%)
Max power 8.6KW(9500r/min±5%)
Max torque 8.5N·m(7500r/min)

Load Quantity 40HQ: 126 units
Load Quantity 40HQ: 210 sets
