| Emoto Boxer | |
| Size(mm) | 2020×730×1050 |
| Wheelbase(mm) | 1330 |
| Minimum ground clearance(mm) | 170 |
| Brake type(drum/drum) | Drum/Drum |
| Brake operate mode | Hand/kick |
| Wheel type | Alloy front 1.6×18 , rear 1.85×18 |
| Tyre size | Front 2.75-18, rear 90/90-18 |
| Max speed(km/h) | 80 |
| Full charge range(KM) | 80-120 |
| Ingress Protection level | IP67 |
| Gradient level(degree) | 30 |
| Motor | |
| Type | 130mm Mid-drive |
| Voltage(V) | 72 |
| Power(kW) | 3 |
| Transmission type | Chain |
| Battery | |
| Capacity(AH) | 60 |
| Voltage(V) | 76.8 |
| Max recharge Voltage(V) | 86.4 |
| Voltage range(V) | 48~86.4 |
| Battery life（cycle) | 1850 |
| Recharge time(H) | 15A 5H |
| SKD package size(mm) | 1815x460x850 |
| SKD load quantity | 90 units |
| CKD load quantity | 150 units |
