KSR 125

$0,00 降价提醒
  • Disponibilidade: 1

总价 $0,00
Quantidade mínima para compra: 50
 Model: KSR 125
Dimension.(L×W×H)(mm) 1860×720×860
Wheel base(mm) 1225
Min ground clearance(mm) 180
Seat height(mm) 760
Turning angle <48°
Min turning radius(mm) 1860
Front/rear sprocket teeth 14/35
Gearshift 4-forward
Fuel tank(L) 9L
 Fuel Type Gasoline
Max. Load Capacity(kg) 150
Dead Weight(kg) 93
Displacement/Power(ml/kw): 125cc
Eco fuel consumption(L/100km) 2.2L
Brake Mode: Front Wheel Disc brake
Rear Wheel Disc brake
  Front Wheel Manual
Brake Operation Mode Rear Wheel kick
Wheel Rim Type Front spoke wheel:        2.50-12
Rear spoke wheel:          2.50-12
Tire type With tube
Front tire 100/90-12
Rear tire 100/90-12
Head light 12V  35W/35W
Winker 12V  10W
Battery(mm) Maintenance Free: YTX5L-BS    114×71×106

 Engine Model 156FMI
Engine Type 1-Cylinder, 4-stroke, air-cool, Single Over Head Camshaft
Start Electric and kick
Ignition CDI
Bore×Stroke 56.5×49.5
Displacement(ml) 125cc
Compression rate 9.1:1
Magneto 12V 6 head, full phase
Oil Capacity(ml) 800
Spark plug A7TC
Spark clearance(mm) 0.6~0.7
Valve clearance(mm) 0.05~0.06
Lubriation type Press and splash
Carburetor PZ19
Transmission Constant mesh, 4-forward, with high shift protection
Clutch type Automatic, wet type, offcenter
Initial rate 3.722
Gears rate 1st: 3.273,2nd: 1.938,3rd: 1.350,4th: 1.043
Final trans Chain
Rotation direction Facing shaft, unclock wise
Size(mm) 477×395×280
Net Weight(kg) 25
Rated Power 7.0KW(8000r/min±5%)
Max Power 7.8KW(9000r/min±5%)
Max Torque 8.5N·m(7500r/min)
Min fuel comsumption(g/kw.h) 367
