| Model： | NAVI 125 | |
| Dimension.(L×W×H)(mm) | 1805×748×1039 | |
| Wheel base(mm) | 1286 | |
| Min ground clearance (mm) | 130 | |
| Seat height(mm) | 760 | |
| Turning angle | ＜48° | |
| Min turning radius(mm) | 2120 | |
| Front/rear sprocket teeth | Bel transmission | |
| Gearshift | CVT | |
| Fuel tank(L) | 3.5L | |
| Fuel Type | Gasoline | |
| Max. Load Capacity(kg) | 75 | |
| Dead Weight(kg) | 100 | |
| Displacement/Power(ml/kw): | 125c c | |
| Eco fuel consumption(L/100km) | 2 | |
| Brake Mode： | Front Wheel | Disc brake |
| Rear Wheel | Drum brake | |
| Front Wheel | Manual | |
| Brake Operation Mode | Rear Wheel | kick |
| Wheel Rim Type | Front aluminum wheel: 1.60×12 | |
| Rear aluminum wheel: 2.50×10 | ||
| Tire type | With tube | |
| Front tire | 110/70-12 | |
| Rear tire | 3.50-10 | |
| Head light | 12V 35W/35W | |
| Winker | 12V 10W | |
| Battery（mm） | Maintenance Free: 12V4AH 114×71×106 | |
| Engine type | 1-Cylinder, 4-stroke, air-cool, OHC | |
| Engine Model | 152QMI | |
| Start | Electric+kick | |
| Ignition | CDI | |
| Bore×Distance | 52.4x57.9 | |
| Displacement(ml) | 124cc | |
| Compression rate | 9.2：1 | |
| Magneto | 12V 8head full phase | |
| Oil capacity(ml) | 1100 | |
| Spark plug | D8EA | |
| Spark clearance(mm) | 0.6~0.7 | |
| Valve clearance(mm) | 0.04~0.06 | |
| Lubriation | press+splash | |
| Carburetor | Valcuum | |
| Transmission | Constant mesh | |
| Clutch type | Manual, multi-disc | |
| Initial trans rate | CVT | |
| Gearshift rates | CVT | |
| Final trans | belt | |
| Rotation direction | Facing shaft, unclock wise | |
| Size(mm) | ||
| N.W.(kg) | 31 | |
| Max power | 8.3KW(8500r/min±5%) | |
| Max torque | 12N·m(5000r/min) | |
| Load Quantity | 40HQ | 126units |
