| Model： | H2 2-muffler 250 |
| Dimension.(L×W×H)(mm) | 2010×715×1110 |
| Wheel base(mm) | 1410 |
| Min ground clearance (mm) | 150 |
| Seat height(mm) | 780 |
| Turning angle | ＜48° |
| Min turning radius(mm) | 2120 |
| Front/rear sprocket teeth | 17/42 |
| Gearshift | 5-forward |
| Fuel tank(L) | 17L |
| Fuel Type | Gasoline |
| Max. Load Capacity(kg) | 150 |
| Dead Weight(kg) | 132 |
| Displacement/Power(ml/kw): | 250㏄ |
| Eco fuel consumption(L/100km) | 2.5 |
| Brake Mode： | Front Wheel: Disc brake |
| Rear Wheel: Disc brake | |
| Brake Operation Mode | Front Wheel: Hand clip |
| Rear Wheel: Kick | |
| Wheel Rim Type | Front aluminum wheel: 2.50×17 |
| Rear aluminum wheel: 3.50×17 | |
| Tire type | With tube |
| Front tire | 110/70-17 |
| Rear tire | 140/70-17 |
| Head light | 12V 35W/35W |
| Winker | 12V 10W |
| Battery（mm） | Maintenance Free: 12V7AH 114×71×106 |
| Engine type | 1-Cylinder, 4-stroke, air-cool, with balancer |
| Engine Model | ZS167FMM-B, CG engine, 6-gears |
| Start | Electric+kick |
| Ignition | CDI |
| Bore×Distance | 67×65 |
| Displacement(ml) | 229.5 |
| Compression rate | 8.7：1 |
| Magneto | 12V 8head full phase |
| Oil capacity(ml) | 1100 |
| Spark plug | D8EA（NGK） |
| Spark clearance(mm) | 0.6~0.7 |
| Valve clearance(mm) | 0.04~0.06 |
| Lubriation | press+splash |
| Carburetor | PZ30 |
| Transmission | Constant mesh |
| Clutch type | Manual, multi-disc |
| Initial trans rate | 3.333 |
| Gearshift rates | 1st: 2.769 2nd: 1.882 3rd: 1.400 4th 1.130，fifth: 0.960 6th: 0.87 |
| Final trans | Chain |
| Rotation direction | Facing shaft, unclock wise |
| Size(mm) | 470×410×450 |
| N.W.(kg) | 31 |
| Max power | 12.5KW(7000r/min±5%) |
| Max torque | 16.5N·m(5500r/min) |
| Load Quantity | 40HQ:72 units |
