| Model： | Duro 200 |
| Dimension.(L×W×H)(mm) | 2080×840×1180 |
| Wheel base(mm) | 1360 |
| Ground (mm) | 265 |
| Seat height(mm) | 860 |
| Turning angle | ＜48 degree |
| Min turning radius(mm) | 2120 |
| Front/rear sprocket teeth | 17/50 |
| Gearshift | 5-forward |
| Fuel tank(L) | 9L |
| Fuel Type | Gasoline |
| Max. Load Capacity(kg) | 150 |
| Dead Weight(kg) | 121 |
| Displacement/Power(ml/kw): | 200cc |
| Eco fuel consumption(L/100km) | 2.5L |
| Brake Mode： | Front Wheel: Disc |
| Rear Wheel: Drum | |
| Wheel Rim Type | Front spoke wheel: 1.85*21 |
| Rear spoke wheel: 2.15*18 | |
| Tire type | With tube |
| Front tire | 80/100-21 |
| Rear tire | 110/100-18 |
| Head light | 12V 35W/35W |
| Winker | 12V 10W |
| Battery（mm） | With acid: 12V6.5A |
| Engine type | 1-Cylinder, 4-stroke, air-cool, OHC |
| Engine Model | 163FML-B |
| Start | Electric+kick |
| Ignition | CDI |
| Bore×Distance | 63.5*62.2 |
| Displacement(ml) | 197 |
| Compression rate | 9.2：1 |
| Magneto | 12V 8head full phase |
| Oil capacity(ml) | 1100 |
| Spark plug | D8EA（NGK） |
| Spark clearance(mm) | 0.6~0.7 |
| Valve clearance(mm) | 0.04~0.06 |
| Lubriation | press+splash |
| Carburetor | PZ30 |
| Transmission | Constant mesh |
| Clutch type | Manual, multi-disc |
| Initial trans rate | 3.333 |
| Gearshift rates | 1st: 2.769 2nd: 1.882 3rd: 1.400 4th 1.130，fifth: 0.960 |
| Final trans | Chain |
| Rotation direction | Facing shaft, unclock wise |
| Size(mm) | 388×324×446 |
| N.W.(kg) | 31 |
| Rated power | 10.2KW(8000r/min±5%) |
| Max power | 10.8KW(8000r/min±5%) |
| Max torque | 13N·m(7000r/min) |
